- Place of Origin: CHINA
- Brand Name: JIADIHAO
- Model Number: W65
Specifications
Aluminum sliding window
1.Thermal break aluminum profile
2.Superior window
3.Resonable price
4.ISO 9001,SGS Certificate
Aluminum window
1. Profile in common use, aluminum profile adopted 14.8 mm and 16.8mm heat insulated strip; 50 series, 77 series, 80 series, 90 series.
2. Can achieving different open styles. Such as: Fix window, awning window, Tilt window and tilt and turn window, sliding window, casement window.
3. European standard C-slot hardware.
4. Use sponge foam composite EPDM to achieve dual sealing and ensure the sealing performance, reducing the force for opening and closing.
5. Side frame, window sash follow the procedure of glue injection after corner crimping; Leading the flow of sealant through the guide plate, increasing the intensity and sealing performance for the corner of window.
6. Using different series of aluminum profiles and different configurations of glass.
- Place of Origin: CHINA
- Brand Name: JIADIHAO
- Model Number: W65
| Thermal Break Aluminum Sliding Window | |
| Material | |
| Profile | Thermal Break |
| Profile Depth | 55mm |
| Profile Thickness | 1.4 mm |
| Profile Surface Treatment | Powder coated, Electrophoresis, Anodize and PVDF |
| Color | RAL Series, and Wood Grain |
| Glass | Single glass, Tempered glass, Low-e glass, floated glass, refective glass, frosted glass, laminated glass and so on |
| Glass Thickness | 5mm/6mm/8mm/12mm for single glass and 5mm 9A 5mm, 6mm 12A 6mm. etc for double/triple glazing |
| Sealant | EPDM, PVC, Silicone Sealant |
| Hardware | Roto, Kin Long |
| Dimension | According to client' s size or drawings |
| Fly Screen | Available |
| Performance Parameter | |
| Sound Isolation | 28-45db |
| Air Pressure | 3 th -5 th Grade |
| Wind Resistance | 3 th -5 th Grade |
| Water Resistance | 3 th -5 th Grade |
| U-Value | 2.2-3.5 |
